High Temperature Urethane Bonded Piston for Mud Pump

Our high temperature urethane bonded mud pump pistons improve drilling contractor economics through advances in technology, improved process control and increased drilling penetration rates. This advanced proprietary chemical formula provides increased resistance to water, oil and synthetic drilling fluids, while providing increased temperature, abrasion and particle embedment resistance. The advanced polymer compound provides strength to withstand chemical attack from additives used in today's oil, synthetic and water based drilling fluids. The compound also has improves abrasion resistance from drilling solids suspended in drilling muds and excels in high temperature performance capable of operating in fluid temperature up to 325°F. Our improved process control, allow us to monitor the piston body by engraving the manufacturers dates on each product. CNC machining of steel piston heads yields close tolerances for improved performance.

Design Features

● 100% interchangeable with the most common brands of mud pumps.

● Available Piston Size: 3 ~ 7-1/2 in

● Pressure Rate: 7,500 psi

● Temperature Rate: 325℉

● Suitable muds: All based muds

● Excellent chemical and abrasion resistance in the most demanding well conditions.

● Reduced cost per operating hour and consistent run times.

● Reduced maintenance and downtime.

● Flex Lip design for decreased liner wear

Parameter

We provide High Temperature Urethane Bonded Pistons for the following brands:

Mud Pump Brand Mud Pump Model
Bentec T-1600-AC
Drillmec 9T800, 9T1000, 12T1600
EMSCO F-500, F-800,F-1000, F-1300, F-1600, FB-1300, FB-1600, FC-1600, FC-2200
Gardner Denver TEE, PAH, PZ-7, PZ-8, PZ-9, PZ-10, PZ-11, PXL-2000
IDECO T-500, T-800, T-1000, T-1300, T-1600
LEWCO W-446, WH-1612, W-2200, W-2214, W-2215
Oilwell A-560-PT, A-850-PT, A-1100-PT, A-1400-PT, A-1700-PT
MH Wirth TPK-800, TPK-1000, TPK-1300, TPK-1600, TPK-2000, TPK-2200
National JW165, JW-340, JW-400, 7-P-50, 8-P-80, 9-P-100, 10-P-130, 12-P-160, 14-P-220
TSC WF-700, WF-1000, WF-1300, WF-1600, WF-2000, WF-2200
HONGHUA HHF-500, HHF-800, HHF-1000, HHF-1300, HHF-1600, HHF-1600HL, HHF-2200HL
Bomco F-500, F-800, F-1000, F-1300, F-1600, F-1600HL
Lanshi  3NB-1300C, 3NB-1000, 3NB-1000C, 3NB-800
Weatherford MP-5, MP-8, MP-10, MP-13, MP-16, E-447, E-800, E-1100, E-1600, E-2200, EQ-2200
Russian pumps 8T-650, UNBT-600, UNBT-950, UNBT-1180L, UNBT-950A, UBT-400, BT-600, UB-590, UNB-600, 8T-310, 8T-650
